ZC-450F China Full Automatic edge banding machine

Can choose manual knife adjustment, pneumatic knife touch screen pneumatic knife clamping style.

Applicable products: solid wood panels, fibreboard, particleboard, MDF and other panels and other panel furniture Edge. Edge of the main PVC, polyester, melamine and wood, and so on.


Achieve results: a high degree of automation, high efficiency, high precision and high aesthetics.


Structural advantages: laser cutting steel plate base, a welded body made of solid deformation does not increase the stability of the machine to ensure that each processing department can work fine. Processing components imported motor and high- quality electrical components.

Contact Us




Technical Parameters

Working thickness10-60mm
Min. working width≥60mm
Min. panel length≥160mm
Feeding speed18-24m/min
Tape thickness0.4-3mm
Air pressure0.6Mpa
Total power16.8KW
Voltage380v,50hz, 3phase
Power of main drive motor3.7KW
Weight3000kg
Overall size6800*1100*1600mm
